Fuel Injector Circuit Wiring Diagram (1995 1.6L Honda Civic)

With SRS (Airbags)

APPLIES TO: This fuel injector circuit wiring diagram applies to the following vehicles:

You can find the fuel injector wiring diagram for the 1996-2000 1.6L Honda Civic here:

Fuel Injector Test: You can find the fuel injector multimeter test here:

APPLIES TO: This fuel injector circuit wiring diagram applies to the following vehicles:

You can find the fuel injector wiring diagram for the 1996-2000 1.6L Honda Civic here:

Fuel Injector Test: You can find the fuel injector multimeter test here:

You can find a complete list of tutorials in this index:

Here's a small sample of the 1.6L Honda Civic tutorials you'll find in the index:
